G4X Monsoon Wire-In Bundle. Everything you need to get started wiring a Link G4X MonsoonX ECU into your chosen vehicle.
This package is ideal for four cylinder engines requiring a few additional features.
- Link G4X MonsoonX ECU
- Medium A Loom - 2.5m length A loom for G4X ECUs (MonsoonX)
- Air temperature sensor
- Coolant temperature sensor
- 10 bar Pressure sensor
G4X Monsoon Wire-In Bundle - ECU + Loom + Sensors
Inputs:
4 x Digital inputs
2 x Temperature inputs
4 x Analog inputs
2 x Trigger inputs
1 x Knock Input (Shared with DI4)
1 x Onboard 4 Bar MAP sensorOutputs:
4 x Injector drives
4 x Ignition drivers
6 x Auxiliary outputs^
+5V Sensor power supply
^unused ignition drives can be used as additional Aux outputsCommunications:
1x CAN bus
1x USB tuning connection
Upgraded communications chip (four times faster than G4+)Physical:
Dimensions: 95mm(L) x 130mm(W) x 45mm(H) (without loom)
Weight: 220 gramsAdvanced features not found on the AtomX:
Antilag, rolling antilag and launch control.
Up to 2 fully variable closed loop VVT cams.Misc:
512MB of logging memory within data storage unit
20 general purpose tables
Runs on PC Link software for G4XThe MonsoonX comes supplied with waterproof connectors, a mounting bracket and a USB tuning cable. “A Loom” to be purchased separately.
